ELD-8201A-B

Features：

Application：

Data Sheet

Product description

Character height:0.8inch.

Category:Dual digit led display.

Common electrode:Common Cathode, Common Anode.

Luminous color:Red,Orange,Yellow,Olivine,Emerald,Blue,White.

Dimensions:35.8x25.8x10.0mm.

Number of pins:10pins.

Common PIN:1,2.

Surface color:Black.

Epoxy color:White.

Operating temperature:-20~80℃.

Storage temperature:-30~80℃.

Lead soldering:255℃,3seconds.

Product parameters

Part No.	Character height	Category	Common electrode	Luminous	Color	Wavelength (nm)	Face Color	Window Color
ELD-8201AS	0.8" inch	Dual digit led display	Common Cathode	Red		620-640	Black Face	White Epoxy
ELD-8201BS	0.8" inch	Dual digit led display	Common Anode	Red		620-640	Black Face	White Epoxy
ELD-8201AG	0.8" inch	Dual digit led display	Common Cathode	Olivine		565-575	Black Face	White Epoxy
ELD-8201BG	0.8" inch	Dual digit led display	Common Anode	Olivine		565-575	Black Face	White Epoxy
ELD-8201AGG	0.8" inch	Dual digit led display	Common Cathode	Emerald		515-525	Black Face	White Epoxy
ELD-8201BGG	0.8" inch	Dual digit led display	Common Anode	Emerald		515-525	Black Face	White Epoxy
ELD-8201AB	0.8" inch	Dual digit led display	Common Cathode	Blue		460-470	Black Face	White Epoxy
ELD-8201BB	0.8" inch	Dual digit led display	Common Anode	Blue		460-470	Black Face	White Epoxy
ELD-8201AW	0.8" inch	Dual digit led display	Common Cathode	White		/	Black Face	White Epoxy
ELD-8201BW	0.8" inch	Dual digit led display	Common Anode	White		/	Black Face	White Epoxy
Note: The above parameters are for reference only,please prevail in kind.

Package dimension and internal circuit diagram (Unit : millimeters , Tolerance : ±0.25mm)
